Medium/Large: 5’6 – 6’0″ height

Sizing is approximate. Please consult with your local bike shop to assist with fit.


Frame: 1020 Steel, with Rack and Fender mounts
Fork: 1020 Steel, 1 1/8”
Handlebar: Fairdale Archer v3, Aluminum
Stem: 70mm, Forged Aluminum
Headset: FSA, Sealed Integrated, 45º/45º
Brake Lever: Aluminum, Short Pull
Brake: Aluminum, Dual Pivot, w/ Quick Release
Grips: Fairdale Swan
Saddle: Fairdale Logo Saddle
Seat Post: Micro adjust, 27.2mm
Seat Clamp: Fairdale, 30mm
Cranks: FSA Tempo 1x (S/M=170mm, M/L=175mm)
Chainwheel: 42t
BB Parts: FSA
Pedals: Odyssey Twisted PC
Rims: 700c, 36H, 16.7mm X-Sec, Schrader Valve, Aluminum, Double-Wall, Pinned Joint
Front Hub: 36H 3/8” Axle, Aluminum Shell, Looseball
Rear Hub: 36H 3/8” Axle, Aluminum Shell, Looseball
Tires: Continental Tour Ride, 700c x 42mm
Chain: KMC S1
Driver: 16t Freewheel



Size S/M (52cm) M/L (56cm)
Top Tube (Effective) 537mm 565mm
Top Tube (Actual) 517mm 546mm
Seat Tube (BB Center to TT Top) 475mm 525mm
Seat Tube
(BB Center to TT Center)
439mm 489mm
Seat Tube Angle 73° 73°
Head Tube Length 130mm 155mm
Head Tube Angle 71° 72.5°
Chain Stay Length 430mm 430mm
Wheelbase 1018mm 1031mm
Standover 770mm 809mm
Stack 554mm 584mm
Reach 368mm 387mm
Fork Length 404mm 404mm
Fork Offset 50mm 50mm
BB Drop 68mm 68mm
Dropout Spacing 130mm 130mm
BB Type English 68mm English 68mm
Seat Post 27.2mm 27.2mm
Seat Clamp 30mm 30mm
Approx. Max Tire Width 42mm 42mm
Wheel Size 700c 700c
